Supported data | E5024 ECDIS Installation Manual
Supported data
ECDIS NMEA 0183 & NMEA 2000 supported sentences
The following
data types are
supported on
E5000
NMEA 0183,
either as RS422
or Ethernet
N2k (RX only).
All N2k data is
translated to
NMEA 0183
before used in
ECDIS application
NMEA Sentence Receive Transmit Receive Translated from PGN
ACK –
Acknowledge
Alarm
x x
ALR – Set Alarm
State
x x
APB – Heading/
Track Controller
(Autopilot)
Sentence "B"
x
DBT – Depth
Below
Transducer
x x 128267
DPT – Depth x x 128267
DTM – Datum
Reference
x All NMEA2000 Data is
in WGS-84 Datum
GGA – Global
Positioning
System Fix Data
x x 129025,129029
GLL –
Geographic
Position
– Latitude/
Longitude
x x 129025,129029
GNS – GNSS Fix
Data
x x 129025,129029
HDT – Heading,
True
x x 127250
MWD – Wind
Direction &
Speed
x x
MWV – Wind
Speed & Angle
x x
RMC –
Recommended
Minimum
Specific GNSS
Data
x x 127258, 129025,
129026, 129033
ROT – Rate Of
Turn
x x 127251
THS – True
Heading and
Status
x x 127250
TLB – Target
Label
x
TLL – Target
Latitude and
Longitude
x
