14
403825/C
Gettingstarted
Topics
TurningontheEK80system,page14
Startingnormaloperation,page15
Replaydata,page16
Gettingtoknowtheuserinterface,page18
Recorddata,page20
TurningofftheEK80system,page21
TurningontheEK80system
InordertousetheEK80system,youmustrstturniton.Whenthesystemisturnedonyou
canstartnormaloperation,replaydata,recorddataandexploreallfunctionalityprovided.
Prerequisites
•TheEK80Scienticwidebandechosoundersystemunitshaveallbeeninstalled
accordingtotheinstructionsintheEK80Installationmanual.
Caution
Youmustneversetthesystemto"ping"unlessthetransducerissubmergedinwater.Most
transducersaredamagedbeyondrepairiftheytransmitinopenair.Preventinadvertent
useofthesystemwheneveratransducerisnotsubmerged.
SimradEK80Quickstartguide
