18
403825/C
Gettingtoknowtheuserinterface
TheEK80consistsofspecicvisualelementsthatworktogether.Thevisualelements
provideyouwiththeechoinformationyouneed,theyhelpyoutocontrolthefunctionality
neededtounderstandthisinformation,andnally,theyallowyoutocontroltheoperational
parameters.Bydefault,theEK80presentationcoverstheentirescreen.
ATopbar
BReplaybar
CEchogramview
DInformationpanes
EMainmenu
FSecondarymenus
GBottombar
Procedure
1Movethecursortothetopbar,andinvestigatethefunctionsprovided.
Observethatsmalltooltipsopentoidentifythevariousfunctionsyoucanuse.
SimradEK80Quickstartguide
