Simrad EQ44 User Manual

◄
GAIN-
Navigation Compass Wind Al
GAIN+
►
Water depth input: INTERNAL ONLY
Group selection: SIMRAD
Source (multiple available):
Simrad EQ44 ,Sn:100003
Water temperature input:
Group selection: SIMRAD
Source (one available):
Airmar EQS ,Sn:000000
Water temperature offset: +0.0°C
Water speed input:
Group selection: SIMRAD
Source (one available):
Airmar EQS ,Sn:000000
LOG speed cal.: 019000 PULSES/nm
NMEA0183 output: NMEA1 NMEA2
Water temperature: MTW ON ON
Water speed and heading: VHW ON ON
Depth: DPT ON ON
Depth below keel: DBK OFF OFF
Depth below surface: DBS OFF OFF
Depth below transducer: DBT OFF OFF
MENU
Exit Accept
ENT
∆
∆
Water
Chapter 10-10 EQ44/54 SETUP menu
GAIN+
Go to Water interface - step back with [GAIN-]
Input:
INTERNAL ONLY - indicates that no external source can be
selected for depth.
Water temperature offset - a figure can be keyed in to compensate
for differencies in temperature sensor.
LOG speed calibration - the unit is preset to receive 19000 pulses
per nautical mile from the log transducer (paddle wheel). However
the figure might have to be changed to compensate for various trans-
ducers and actual water flow passing the transducer. The correct
pulse rate is calculated by:
19000 x indicated speed (e.g. 4kn)
= 15.200 pulses/nm
actual speed (GPS) (e.g. 5kn)
NMEA0183 output - see also section 10.4.1 Description of sentences.
