Technical specications | HS80/HS80A/MX575C/MX575D User Manual

(13) PCSI - Beacon Status Message

This message contains a variety of information relating to the status of Beacon engine

inside the MX575C/MX575D. The $PCSI,1 output message from the SBX beacon module

is intelligently routed through the MX575C/MX575D to the port from which the $PCSI,1

message was requested.

$PCSI,CS0,PXXX-Y.YYY,SN,fff.f,M,ddd,R,SS,SNR,MTP,Q,ID,H,T

1 2 3 4 5 6 7 8 9 10 11 12 1314

¼ Notes:

1 Channel 0

2 Resident SBX-3 ﬁrmware version

3 SBX-3 receiver serial number

4 Channel 0 current frequency

5 Frequency Mode (‘A’ - Auto or ‘M’ - Manual)

6 MSK bit rate

7 RTCM rate

8 Signal strength

9 Signal to noise ratio

10 Message throughput

11 Quality number {0-25} - number of successive good 30 bit RTCM words

received

12 Beacon ID to which the receiver’s primary channel is tuned

13 Health of the tuned beacon [0-7]

14 $PCSI,1 status output period {0-99}
