| 3
Preface | HS80/HS80A/MX575C/MX575D User Manual
Contents
4 Introduction
4 Overview
5 Parts list
6 Installation
6 Mounting location
8 Mounting orientation
9 Mounting options
15 Ports
19 Powering the Smart GPS compass
20 Connecting the Smart GPS compass to external devices
21 Default parameters
22 Operation
22 GPS overview
22 GLONASS overview
23 Smart GPS compass overview
27 Common commands and messages
31 Technical specications
31 Specifications
32 Certifications
34 Output messages
41 Proprietary Input data messages
48 Troubleshooting
50 List of abbreviations
51 Wiring Diagrams
51 MX420 CDU to GPS compass interface diagram
51 MX510/MX512 to GPS compass interface diagram
52 GPS compass interface via MX510 junction Box
53 MX512 to GPS compass interface diagram via MX512 Junction Box
54 1PPS output
54 PC to GPS compass interface diagram
55 GPS compass connection to the MX61xJB junction box.
57 HS80/HS80A connection via the NMEA 2000 network
