Simrad HS80 User Manual

54 |
Wiring Diagrams | HS80/HS80A/MX575C/MX575D User Manual
1PPS output
BLK (-)
YEL/BLK (Port B TX-)
YEL (Port B TX+)
BLK/BRN (Port B RX-)
BRN (Port B RX+
HS80/HS80A
MX575C/MX575D
BLK/GRN (Port A TX-)
GRN (Port A TX+)
ORG (1 PPS+)
*ORG/BLK (1 PPS-)
+
12-24 VDC
GND
To 1 PPS
Load
PC to GPS compass interface diagram
BLK (-)
YEL/BLK (Port B T X-)
YEL (Port B TX+ )
BLK/BRN (Port B RX-)
BRN (Port B RX+
HS 80/HS80A
M X575C/MX575D
BLK/G RN (Port A TX-)
G RY (G ND)
+12-24 VDC
G ND
2
3
5
d
B-9
C
onnector
