Wiring Diagrams | HS80/HS80A/MX575C/MX575D User Manual
HS80/HS80A connection via the NMEA 2000 network
T
12/24V DC
MX61xJB
Junction Box
12/24V DC
Where:
N2K Backbone
Drop line
NMEA 0183 line
GN70/MX610/MX612
HS80/HS80A
GPS Compass
Ports 3&4
Port 2
Port 1
N2K Converter
T
