56 |
Wiring Diagrams | HS80/HS80A/MX575C/MX575D User Manual
REMOTE
PORT1 PORT2
PORT3 PORT4 SUPPLY
+ -
TERMINATION
SIMNET
SIMNET
BRN
BLK/BRN
YEL
YEL/BLK
GRN
BLK/GRN
RED
BLK
MX575C/MX575D
GPS Compass
MX61xJB PCB Terminals
ANTENNA CABLE
000-10939-001 (15 m)
000-10940-001 (30 m)
Speed Log+
Speed Log -
RX+
RX-
TX+
TX-
NMEA 0183 CONNECTOR
TERMINALS
RED
BLK
WHT
BLU
N2K
NEG
12-24 VDC
