Alerts
The system continuously checks for dangerous situations and system faults while the system
is running. When an alert situation occurs, an alert message pops up on the screen. and an
alert icon is displayed in the status bar.
If you have enabled the siren, the alert message is followed by an audible alert.
The alert is recorded in the alert listing so that you can see the details and take the
appropriate corrective action.
The active, historical and settings dialogs are available from the main menu and from the
Alert Settings dialog.
• Active - list of active alerts.
• History - list of all alerts with time stamp.
• Settings - list of all available alert options in the system, with current settings.
The following is an example of an alert message.
Acknowledging an alert message
The close option is available in the alert dialog for acknowledging a message.
Close sets the alert state to acknowledged, meaning that you are aware of the alert
condition. The siren stops and the alert dialog is removed. However, the alert remains active
in the alert listing until the reason for the alert has been removed.
5
Alerts | S2009-2016 Fish Finder User Manual
19

Simrad S2009 Specifications

General

Display Size	9-inch
Display Type	LCD
Resolution	800 x 480 pixels
Interface	Keypad
Waterproof Rating	IPX7
NMEA 2000 Connectivity	Yes
Display	Color LCD
Operating Voltage	10-31.2 V DC
Operating Temperature	-15°C to +55°C
Storage Temperature	-30°C to 70°C
Ethernet Ports	1
NMEA 0183 Ports	1 x NMEA 0183
Frequency	50 kHz, 200 kHz
Depth Range	Up to 3000 m
Transducer Type	Compatible with multiple transducer options
