Simrad S2009 User Manual

Contents
7 The user interface
7
Front panel and keys
8 The main panel
8 Using the cursor on the image
9 Softkeys
10 Slide bars
10 The menu system
12 Basic operation
12 System Controls dialog
12 Turning the system on and off
12 Display illumination
12 Setting the appearance of the Instrument bar
13 Pausing the image
13 Screen capture
13 Show or hide the softkey bar
14 Setting up the image
14 The range
14 Zooming the image
15 Frequency
15 Gain
15 Color
16 View options
17 Split screen options
17 Palettes
18 White marker
18 Temperature graph
18 Bottom line
18 A-Scope
18 Zoom bars
19 Alerts
19 Acknowledging an alert message
20 Advanced options
20 Noise rejection
20 TVG
20 Scroll speed
20 Ping speed
20 Recording log data
22 Files
22 Managing files
22 Exporting the log file
23 Simulator
23 Turning the simulator on/off
23 Simulator source files
24 Installation
24 Mounting location
26 U-bracket mounting
27 Panel mounting
28 Wiring
Contents | S2009-2016 Fish Finder User Manual
5

Simrad S2009 Specifications

General

Display Size	9-inch
Display Type	LCD
Resolution	800 x 480 pixels
Interface	Keypad
Waterproof Rating	IPX7
NMEA 2000 Connectivity	Yes
Display	Color LCD
Operating Voltage	10-31.2 V DC
Operating Temperature	-15°C to +55°C
Storage Temperature	-30°C to 70°C
Ethernet Ports	1
NMEA 0183 Ports	1 x NMEA 0183
Frequency	50 kHz, 200 kHz
Depth Range	Up to 3000 m
Transducer Type	Compatible with multiple transducer options
