Simrad S2009 - Dimensional Drawings; S2009

Dimensional drawings
S2009
247 mm (9.72”)
224 mm (8.81”)
219 mm (8.62”)
80 mm
(3.14”)
67 mm
(2.63”)
100 mm (3.93”)
280 mm (11.02”) 260 mm (10.23”)
S2016
+
_
280 mm (11.02”)
80 mm
(3.14”)
67 mm
(2.63”)
100 mm (3.93”)
455 mm (17.91”)
477 mm (18.77”)
505 mm (19.88”)
13
50
Dimensional drawings | S2009-2016 Fish Finder User Manual
