Technical specifications
Ú
Note: The most up-to-date specifications list is available at: navico-commercial.com/
Display
Display type LED-backlit Color TFT LCD
Display brightness S2009 = 1200 cd/m2
S2016 = 400 cd/m2
Display resolution S2009 = 480 x 800
S2016 = 1366 x 768
Display size S2009 = 9-inch portrait
S2016 = 16-inch landscape
Video integration (S2016 only) 1x HDMI output (Supported resolutions:
1366 x 768)
Overview
Output power 1 kW RMS
Echosounder Max Depths 3,000 m (10,000 ft), transducer-dependent
Echosounder Transducer Standard Broadband and single-channel
CHIRP Transducers
Echosounder Frequencies CHIRP 28-38 kHz, 40-60 kHz, 85-145 kHz,
130-210kHz
Broadband 28kHz, 38kHz, 50kHz, 83kHz,
200kHz
Technical/Environmental
Water Resistance IPX7
Operating Temperature - 15°C to +55°C (5°F to 131°F)
Dimensions Refer to "Dimensional drawings" on page 50
Weight S2009 = 2 kg (4.4 lb)
S2016 = 4 kg (8.8 lb)
Electrical
Power Supply (Supply Voltage) 12-24 V DC
Power Consumption S2009 = 11 W
S2016 = 20 W
Connectors
Power (10.8-31.2 V DC) 1 port, 4-pin
HDMI 1 port (S2016 only)
Echo (for transducer) 1 port, 7-pin
NMEA 2000 (compliant) 1 port, 5-pin
12
48
Technical specifications | S2009-2016 Fish Finder User Manual

Simrad S2009 Specifications

General

Display Size	9-inch
Display Type	LCD
Resolution	800 x 480 pixels
Interface	Keypad
Waterproof Rating	IPX7
NMEA 2000 Connectivity	Yes
Display	Color LCD
Operating Voltage	10-31.2 V DC
Operating Temperature	-15°C to +55°C
Storage Temperature	-30°C to 70°C
Ethernet Ports	1
NMEA 0183 Ports	1 x NMEA 0183
Frequency	50 kHz, 200 kHz
Depth Range	Up to 3000 m
Transducer Type	Compatible with multiple transducer options
