Damping
If data appears erratic or too sensitive, damping may be applied to make the information
appear more stable. With damping set at MIN, the data is presented in raw form with no
damping applied. This is available for heading, course over ground, speed over ground,
apparent wind, true wind, boat speed, depth, and tide sourced from NMEA 2000.
Calibration
An offset (positive or negative) can be applied to correct inaccuracies in boat speed, sea
temp, air temp, barometric pressure, and depth sourced from NMEA 2000 devices.
NMEA 2000
Use the NMEA 2000 network settings option to receive and send waypoints from or to NMEA
2000 devices.
NMEA 0183 setup
The NMEA 0183 port must be set to suit the speed of connected devices, and can be
configured to output only the sentences required by listening devices.
Receive waypoint
Select this option to allow a device capable of creating and exporting waypoints via NMEA
0183 to transfer directly to this unit.
Serial ports
Specify the baud rate for port for the devices connected to the NMEA 0183. The baud rate
should be set to correspond with devices connected to the NMEA 0183 input and output.
The input and output (Tx, Rx) use the same baud rate setting.
44
Software Setup | S2009-2016 Fish Finder User Manual
