Simrad TP32 User Manual

20 |
- To select StandAlone mode, press and hold the TACK and the
port ( ) keys or TACK and starboard ( ) keys while turning
power on
Keep the keys pressed until the Tillerpilot beeps 3 times and all the
LEDs light briefly to confirm the new configuration.
¼ Note: Please refer to the instructions supplied with the relevant
command unit for details on remote configuring of data sources.
¼ Note: If there is more than one data source on the SimNet bus, but
no command unit capable of re-configuring the Tillerpilot present,
the required data source must be the only one present on the bus
when StandAlone mode is selected. Power down or disconnect any
multiple sources until after the operation mode selection process is
complete.
¼ Note: Changing the operation mode, or even re-selecting the same
mode, will reset any data source selections that the Tillerpilot was
previously locked on to.
¼ Note: If any one of the external data sources is replaced, then
the Tillerpilot must be instructed to use the new data source by
following the relevant procedure for StandAlone or System mode.
Interfacing via NMEA
The inbuilt NMEA processor allows NMEA 0183-compatible
equipment to be connected directly to the TP22 and TP32, without
any need for a separate interface unit.
SimNet
GPS/
Chartplotter
Wind Speed
Tillerpilot
power

Simrad TP32 Specifications

General

Type	Autopilot
Operating Voltage	12 V
Auto Seastate	Yes
Course Accuracy	± 1°
Operating Temperature	-15°C to +55°C
Keypad	Yes
Power Supply	12 V DC
Power Consumption	0.5 A
Peak Thrust	80 kg (176 lbs)
Display	No
