Simrad TP32 User Manual

| 27
Spares & accessories
The following spares and accessories are available from local Simrad
agents. Please quote the part number when ordering.
TPPK7 Tillerpin, Mounting Cup & Pushrod End Cap
SKT100 Waterproof Socket & Cable Assembly (TP10)
SKT22/32 Waterproof Bulkhead Socket & Cable
Assembly (TP22 and TP32)
Mounting accessories
Height
Tiller Brackets
Push Rod Extensions
PRE30
PRE60
PRE90
PRE120
PRE150
PRE300
Part No Length
30mm (1.18")
60mm (2.36")
90mm (3.54")
120mm (4.72")
150mm (5.90")
300mm (11.81")
TB30
TB60
TB90
TB120
Part No Height
30mm (1.18")
60mm (2.36")
90mm (3.54")
120mm (4.72")
Length
PB30
PB60
PB90
CB1 135 - 240mm
(5.31 - 9.44")
Part No Height / Length
30mm (1.18")
60mm (2.36")
90mm (3.54")
Height
Length
Cantilever Bracket CB1
Pedestal & Cantilever Brackets

Simrad TP32 Specifications

General

Type	Autopilot
Operating Voltage	12 V
Auto Seastate	Yes
Course Accuracy	± 1°
Operating Temperature	-15°C to +55°C
Keypad	Yes
Power Supply	12 V DC
Power Consumption	0.5 A
Peak Thrust	80 kg (176 lbs)
Display	No
