Page 24
5.1.2 ELECTRICAL REQUIREMENTS
The facility should provide the following electrical power outputs for Cycraft:
Input Voltage Single Phase
AC 200V, 208V, 220V, 230V, 240V
Frequency 50 / 60 Hz
Rated Current (Max) 8.5 Amp
Peak Current (Max) 10 Amp
Building Circuit Breaker
(Recommended)
13 Amp
Note: The average power requirement is measured power consumption during
normal operation. Peak power requirement is theoretical short-term peak power
possible for short times during special driving conditions. Therefore, it is
recommended that facility power to be based on peak power requirements for the
best results.
5.2 EQUIPMENT REQUIRED FOR INSTALLATION
No Tools Description Q’ty Purpose
1 Philips type
screwdriver
1 Loosening and securing
truss bolts
2 Wrench
(19 mm ~ 27 mm)
1 Adjusting the levers.
3 Hex Key
( 6mm)
1 Boarding step,
Coin Chute Tower
4 Hex Key
( 5mm )
1 Fence
5 Hex Key
(2.5 mm)
1 Photo sensor, mirror
6 Spanner (22 mm) 2 Turnbuckle
Safety Link
