Page 58
Inspection
Point
Part Picture How to check
A Hexahead bolt M12 x 8 points
B Lower joint of heave actuator is inside of
MSCU so in order to inspect the bolts, the
MSCU cover must be removed.
Hexahead bolt M12 x 8 points
C Hexahead bolt M12 x 4 points
D Hexahead bolt M10 x 8 points
E Hexahead bolt M10 x 4 points (Lower)
Hexahead nut M10 x 4 points (Upper)
F
To Next Page
