PRE-OPERATION FUNCTION TEST
1323RE&1623RE Operation Manual 6-13 © Jun. 2021
illuminate with the alarm sounding, and further
lifting and driving is restricted.
8. Lower the platform to the stowed position, the alarm
will stop sounding, and the machine function limit is
cancelled.
9. Drive the machine off and remove the wooden
blocks.
10. With the machine in stowed position (outrigger
extended), place 2 wooden blocks near the two
wheels on the left or right side, then drive the
machine upon the wooden blocks. The wooden
block dimension (L×W×H) is 100×50×28mm
(4in×2in×1.1in).
11. Switch from drive to platform lift function, and raise
the platform until the lower limit switch disengages,
the red indicator light on the level sensor will
illuminate with the alarm sounding, and further
lifting and driving is restricted.
12. Lower the platform to the stowed position, the alarm
will stop sounding, and the machine function limit is
cancelled.
13. Drive the machine off and remove the wooden
blocks.
TESTING THE DRIVE SPEED
With the machine in stowed position:
1. Turn the Ground/Platform select switch on ground
controller to Platform.
2. Pull out the emergency stop buttons on ground and
platform controllers to ON position.
3. Press the drive switch.
4. Hold the joystick enable switch and slowly deflect
forward the joystick to full stroke.
5. Press the drive high/low speed switch on platform
controller to select the high drive speed.
6. The max drive speed of the machine in stowed
position is 5.3±0.53Km/h（3.3±0.33mph），or the
drive time for 40m (131 ft) is 25～30s.
7. Hold the joystick enable switch and slowly deflect
forward the joystick to full stroke.
8. Press the drive high/low speed switch on platform
controller to select the low drive speed.
9. The max drive speed of the machine in stowed
position is 2±0.2Km/h（1.2±0.12mph），or the
drive time for 20m (65.6 ft) is 32～40s.
With the machine in operating position:
1. Turn the Ground/Platform select switch on ground
controller to Platform.
2. Pull out the emergency stop buttons on ground and
platform controllers to ON position.
3. Press the platform lift switch.
4. Hold the joystick enable switch and slowly deflect
forward the joystick to raise the platform, and
release the joystick when the down limit switch
disengages.
5. Press the drive switch.
6. Hold the joystick enable switch and slowly deflect
forward the joystick to full stroke.
7. Press the drive high/low speed switch on platform
controller to select the low drive speed.
8. The max drive speed of the machine is 1.1±0.1Km/
h（0.68±0.06mph），or the drive time for 20m
(65.6 ft) is 53～64s.
9. Hold the joystick enable switch and slowly deflect
forward the joystick to full stroke.
10. Press the drive high/low speed switch on platform
controller to select the low drive speed.
11. The max drive speed of the machine in stowed
position is 1.1±0.1Km/h (0.68±0.06mph), or the
drive time for 20m (65.6 ft) is 53～64s.
NOTICE
if the machine drive speed exceeds the test results
above, immediately tag and remove the machine
from service.
TESTING THE OSCILLATE
OUTRIGGERS
NOTICE
Do not stand in the platform but on the ground to
perform this testing using platform controller.
The oscillate outriggers enables the machine to drive
on uneven surfaces with 4 tires in close contact with the
ground, thus improving the traction performance and
stability.
• With the machine in stowed position:
1. Start the machine from the platform controller
and select the high idle speed.
2. Drive the machine to allow the left steer wheel to
stand on a 10cm (3.9in) high block or kerb.
3. The other 3 wheels should come in close contact
with the ground.
4. Drive the machine to allow the right steer wheel
to stand on a 10cm (3.9in) high block or kerb.
