© Oct 2020 6-24 AB18EJ&18HJ Maintenance Manual
REPAIR PROCEDURES
Fault
code
Description
Cause Check
from an excessively large current, re-
match the motor if necessary.
Note：The pins #7 and #8 of the 35–pin
controller connector are for motor temperature
sensor.
0328
Reduced overheat
performance of RL motor
controller
0428
Reduced overheat
performance of RR motor
controller
0029
Temperature sensor fault
of pump motor controller
1. Motor temperature
sensor fault;
2. Setup error of motor
temperature sensor
type
1. Check the wiring of motor temperature
sensor;
2. Check the setup of motor temperature
sensor via programme/motor menu/
temperature control sensor type.
3. Replace the motor temperature sensor.
Note：The pins #7 and #8 of the 35–pin
controller connector are for motor temperature
sensor.
0129
Temperature sensor fault
of FL motor controller
0229
Temperature sensor fault
of FR motor controller
0329
Temperature sensor fault
of RL motor controller
0429
Temperature sensor fault
of RR motor controller
0031
Open/short-circuited drive
1 output/main contactor of
pump motor controller
1. Driver 1 wiring fault;
2. Loading device fault;
3. Contactor fault.
1. Ensure the correct wiring and the pins free
of stains or damage;
2. Monitor output signal via monitor menu/
outputs menu/Driver 1 PWM to check
whether there is output control signal;
3. Check the coil of contactor;
4. Replace the contactor.
Note：The pins #6 of the 35–pin controller
connector is for driver 1 output.
0131
Open/short-circuited driver
1 output/main contactor of
FL motor controller
0231
Open/short-circuited driver
1 output/main contactor of
FR motor controller
0331
Open/short-circuited driver
1 output/main contactor of
RL motor controller
0431
Open/short-circuited driver
1 output/main contactor of
RR motor controller
0032
Open/short-circuited driver
2 of pump motor controller
1. Drive 2 wiring fault;
2. Loading device fault;
3. Contactor fault.
1. Ensure the correct wiring and the pins free
of stains or damage;
2. Monitor output signal via monitor menu/
outputs menu/Driver 2PWM to check
whether there is output control signal;
3. Check the coil of contactor;
4. Replace the contactor.
Note：The pins #5 of the 35–pin controller
connector is for driver 2 output.
0132
Open/short-circuited driver
2 of FL motor controller
0232
Open/short-circuited driver
2 of FR motor controller
0332
Open/short-circuited driver
2 of RL motor controller
0432
Open/short-circuited driver
2 of RR motor controller
0033
Open/short-circuited
solenoid brake/coil 3
output of pump motor
controller
1. Open/short circuited
coil of solenoid brake;
2. Stained/damaged/
broken wiring
1. Ensure the correct wiring and the pins free
of stains or damage;
2. Monitor output signal via monitor menu/
outputs menu/Driver 3 PWM to check
whether there is output control signal;
3. Check the coil of contactor;
0133
Open/short-circuited
solenoid brake/coil 3
