© Oct 2020 2-6 AB18EJ&18HJ Maintenance Manual
SPECIFICATIONS
ENGINE AND MOTOR
SPECIFICATIONS
Table 2-3 Kubota engine D1105-E4B-EU-X1
Type
Water-cooled
Cylinder
Nuumber
3
Cylinder Bore 78mm (3.07 in)
Stroke
78.4mm (3.09 in)
Displaecement
1.123L
0.25 gal (UK)
0.30 gal (US)
Comression
Ratio
24.0
Firing
Sequence
1-2-3
Output 18.5kW@3000rpm
Torque 71.5Nm (52.78 ft-lb)@2200rpm
Oil capacity
5.1L
1.12 gal (UK)
1.35 gal (US)
Low RPM
1500rpm
High RPM 3000rpm
Table 2-4 Electric Motor
Power 9.5kW
Voltage 29V
Torque 34.9Nm (25.768 ft-lb)
RPM 2600rpm
Frequency 90Hz
Current 265A
FUNCTION SPEED
Table 2-5
ITEM AB18EJ AB18HJ
Main boom up
54～66s 54～66s
Main boom down 54～66s 54～66s
ITEM AB18EJ AB18HJ
Secondary boom up
31～39s 31～39s
Secondary boom
down
31～39s 31～39s
Turntable rotate
(355°)-retracted
80～105s 80～105s
Turntable rotate
(355°)-extended
138～165s 138～165s
Main boom extend 40～50s 40～50s
Main boom retract 31～39s 31～39s
Platform rotate (160°)
12～18s 12～18s
Platform level up
50～60s 50～60s
Platform level down 40～50s 40～50s
Jib up
32～38s 32～38s
Jib down 22～28s 22～28s
Max drive speed
(30m)
15～19s 15～19s
a) The function speed depends on the start and end
point of the movement rather than the controls/
switches.
b) The test results of drive speed vary with tires of
different specifications.
c) All the speed tests should be conducted from the
platform controller, The test results will differ if tested
from the ground controller.
d) All the tests should be conducted with the
hydraulic oil temperature higher than 40℃. If the
hydraulic oil temerature is too low, the test results will
be affected.
Test requirements:
Main boom up/down：With the secondary boom fully
lowered and telescopic boom fully retracted, make the
up and dowm movement of the main boom twice,
respectively.
Secondary boom up/down：Make the up and down
movement of the Secondary boom twice, respectively.
Turntable rotate：With the boom centered, rotate a
turn of the turntable. Test twice.
Main boom extend/retract：With the main horizontal,
extend the main boom from the fully retracted to fully
extended position and retract the main boom from the
fully extended to fully retracted position twice,
respectively.
Platform rotate：With the platform horizontal, rotate
the platform clockwise and anticlockwise twice,
respectively.
