AB18EJ&18HJ Maintenance Manual 2-1 © Oct 2020
2 SPECIFICATIONS
PERFORMANCE
PARAMETERS
Table 2-1 AB18EJ specifications
MEASURE
AB18EJ (Metric) AB600EJ (Imperial)
DIMENSION PARAMETERS
Max platform height
18.2 m 59 ft 8.5 in
Max working height
20.2 m 66 ft 3 in
Max horizontal reach 11.5 m 37 ft 9 in
Overall length(stowed)
8.7 m 28 ft 6.5 in
Overall width(stowed)
2.49 m 8 ft 2 in
Overall height (stowed)
2.56 m 8 ft 4.8 in
Wheelbase 2.49 m 8 ft 2 in
Ground clearance 0.25 m 9.8 in
Tire size (spec / type) 355/55D625 (foam-filled)
Platform dimension (L×W×H)
1.83 × 0.85 × 1.1 m 72 × 33.5 × 43 in
PERFORMANCE PARAMETERS
Platform capacity
230 kg (unrestricted / 2 persons &
tools)
507 lb (unrestricted / 2 persons &
tools)
Turntable rotation / continuous 355°/uncontinuous
Platform rotation 160°
Max drive speed (stowed)
6.5 km/h
4 mph
Max drive speed (raised)
1.1 km/h
0.68 mph
Drive mode (drive×steer)
4WD×2WS
Gradeability
40% / 21°
Turntable tailswing
0.8 m
2 ft 7.5 in
Max allowable inclination 5°
Turning radius (inside)
2.4 m 7 ft 10.5 in
Turning radius (outside)
5.55 m 18 ft 2.5 in
Max allowable side force 400 N 90 lbf
Max operating noise level
82 dB
IP grade
IP54
