© Oct 2020 5-26 AB18EJ&18HJ Maintenance Manual
MAINTENANCE PROCEDURES
9. Move the drive high/low speed select switch on the
platform controller to select the drive low speed.
10. Depress the footswitch.
11. Slowly push forward the drive/steer joystick to the
full drive speed.
12. The test results are shown inTable 5-13 , page 5-
26
Electric mode
1. Turn the Ground/Platform select switch on the
ground controller to the platform position.
2. Pull out the emergency stop buttons on both the
ground and platform controllers to the ON position.
3. Select the electric drive mode.
4. Move the drive high/low speed select switch on the
platform controller to select the drive high speed.
5. Depress the footswitch.
6. Slowly push forward the drive/steer joystick to the
full drive speed.
7. The test results are shown in Table 5-12 , page 5-
26:
8. Move the drive high/low speed select switch on the
platform controller to select the drive low speed.
9. Depress the footswitch.
10. Slowly push forward the drive/steer joystick to the
full drive speed.
11. The test results are shown in Table 5-13 , page 5-
26
Table 5-12
MODELS TEST RESULTS
AB18EJ
Boom in non-operating position: the
max drive speed is 6.5 km/h (4 mph).
Boom in operating position: the max
drive speed is 1.1 km/h (0.7 mph).
AB18HJ
Boom in non-operating position: the
max drive speed is 6.5 km/h (4 mph).
Boom in operating position: the max
drive speed is 1.1 km/h (0.7 mph).
Table 5-13
MODELS TEST RESULTS
AB18EJ
Boom in non-operating position: the
max drive speed is 6.5 km/h (4 mph).
Boom in operating position: the max
drive speed is 1.1 km/h (0.7 mph).
AB18HJ
Boom in non-operating position: the
max drive speed is 6.5 km/h (4 mph).
Boom in operating position: the max
drive speed is 1.1 km/h (0.7 mph).
NOTICE
If the drive speed exceeds the test results as shown
above, please immediately remove the machine from
service and have it tagged.
B-22 Test Emergency Lowering
(AB18EJ only)
When the engine/motor fails, depending on the actual
conditions, move the emergency power switch on the
ground or platform controller to start the emergency
power unit, and meanwhile move the boom function
switch to actuate the corresponding function.
NOTCIE
•• Emergency power switch is only for temporary
use (with platform stowed) when the engine fails.
•• When the emergency power unit is in use, never
operate two or more functions at the meantime,
otherwise it may overload the auxiliary motor and
pump.
Operating from the ground controller:
1. Turn the Ground/Platform select switch on the
ground controller to the ground control position.
2. Pull out the emergency stop button on the ground
controller to the ON position.
3. Move and hold the emergency power switch on the
ground controller.
4. Move the corresponding boom function switch on
the ground controller to lower the platform.
Operating from the platfrom controller:
1. Turn the Ground/Platform select switch on the
ground controller to the platform control position.
2. Pull out the emergency stop buttons on both the
ground and platform controllers to the ON position.
