© Oct 2020 2-2 AB18EJ&18HJ Maintenance Manual
SPECIFICATIONS
MEASURE
AB18EJ (Metric) AB600EJ (Imperial)
POWER PARAMETERS
Electric motor (rated power, rated
rpm)
9.5 kW, 2600 rpm
Duplex gear pump displacement
8ml/r + 4ml/r
Hydraulic tank capacity 70 L 15.4gal (UK)/18.5gal (US)
Hydraulic system pressure 21 MPa 3046 Psi
Battery (number×voltage, capacity) 8×6 V, 390 Ah
System voltage 48 VDC
Control voltage
12 VDC
GROUND BEARING DATA
Max tire load
4920 kg
10846 lb
Tire contact pressure
556 KPa 81 Psi
ENVIRONMENT REQUIREMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280 ft
Allowable ambient temperature
(lead-acid battery)
-10℃～40℃ 14℉～104℉
Allowable ambient temperature (-
lithium battery)
-20℃～40℃ -4℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃ to 50℃(-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gas,inflammables and explosives.
WEIGHT
Gross weight (unladen) 8100 kg
17857 lb
Note：
a) The working height adds 2m(6ft7in) of human height to platform height。
b) The ground bearing data is approximate value, not factoring the different options,thus it serves only in
adequately safe conditions
c) In different areas, hydraulic oil, engine oil, coolant, fuel and lubrication should be added in accordance with the
environmental temperature.
d) In cold weather, auxiliary devices are needed to start the machines
Table 2-2 AB18HJ specification
MEASURE
AB18HJ (Metric) AB600HJ (Imperial)
DIMENSION PARAMETERS
Max platform height
18.2 m 59 ft 8.5 in
Max working height
20.2 m 66 ft 3 in
Max horizontal reach 11.5 m 37 ft 9 in
