SPECIFICATIONS
AB18EJ&18HJ Maintenance Manual 2-3 © Oct 2020
MEASURE
AB18HJ (Metric) AB600HJ (Imperial)
Overall length(stowed)
8.7 m 28 ft 6.5 in
Overall width(stowed)
2.49 m 8 ft 2 in
Overall height (stowed)
2.56 m 8 ft 4.8 in
Wheelbase 2.49 m 8 ft 2 in
Ground clearance 0.25 m 9.8 in
Tire size (spec / type) 355/55D625 (foam-filled)
Platform dimension (L×W×H)
1.83 × 0.85 × 1.1 m 72 × 33.5 × 43 in
PERFORMANCE PARAMETERS
Platform capacity
230 kg (unrestricted / 2 persons &
tools)
507 lb (unrestricted / 2 persons &
tools)
Turntable rotation / continuous 355°/uncontinuous
Platform rotation 160°
Max drive speed (stowed)
6.5 km/h
4 mph
Max drive speed (raised)
1.1 km/h
0.68 mph
Drive mode (drive×steer)
4WD×2WS
Gradeability
40% / 21°
Turntable tailswing
0.8 m
2 ft 7.5 in
Max allowable inclination 5°
Turning radius (inside)
2.4 m 7 ft 10.5 in
Turning radius (outside)
5.55 m 18 ft 2.5 in
Max allowable side force 400 N 90 lbf
Max operating noise level
82 dB
IP grade
IP54
POWER PARAMETERS
Engine (rated power, rated rpm) 18.5kW, 1500rpm
Electric motor (rated power, rated
rpm)
9.5 kW, 2600 rpm
Duplex gear pump displacement
8ml/r + 4ml/r
Hydraulic tank capacity 70 L 15.4gal (UK)/18.5gal (US)
Fuel tank capacity 60 L 13.2gal (UK)/15.9gal (US)
Hydraulic system pressure 21 MPa 3046 Psi
Battery (number×voltage, capacity) 8×6 V, 390 Ah
System voltage
48 VDC
Control voltage 12 VDC
GROUND BEARING DATA
