© Oct 2020 6-26 AB18EJ&18HJ Maintenance Manual
REPAIR PROCEDURES
Fault
code
Description
Cause Check
Note: The pins #31 and #32 of the 35–pin controller
connector are for encoder AB phase output signals.
0436
Encoder error of RR motor
controller
0037
Open-circuited pump motor
controller
1. Incomplete motor;
2. Improper wiring;
3. Damaged controller.
1. Ensure the 3–phase wiring of UVW free of
open circuit;
2. Use a multimeter to check the UVW power
module works properly;
3. If the steps above fail, replace the motor.
0137
Open-circuited FL motor
controller
0237
Open-circuited FR motor
controller
0337
Open-circuited RL motor
controller
0437
Open-circuited RR motor
controller
0038
Fused main contactor of
pump motor controller
1. Fused contact of main
contactor;
2. Improper wiring.
1. Check the main contactor for fused
contact;
2. Measure the coil voltage to ensure it is
normal;
3. Ensure the correct wiring;
4. If the motor lacks in phase, check the UV
phase for unlinked cable.
0138
Fused main contactor of FL
motor controller
0238
Fused main contactor of
FR motor controller
0338
Fused main contactor of
RL motor controller
0438
Fused main contactor of
RR motor controller
0039
Main contactor engaging
failure of pump motor con
troller
1. Voltage drop between
KSI voltage and
battery voltage too big;
2. The KSI circuit is
series connected to a
large-power unit which
brings the voltage
down;
3. Contactor damage.
1. Use a handhold to monitor the KSI, ensure
the difference between the capacitor
voltage (monitor/outputs menu capacitor
Voltage) and the keyswitch voltage is less
than the threshold(programme/main
contactor/main DNC).
2. Check whether the KSI circuit is
connected to a large-power unit which
leads to the reduced KSI voltage;
3. Use interchange method to determine
whether the contactor is damaged.
0139
Main contactor engaging
failure of FL motor
controller
0239
Main contactor engaging
failure of FR motor
controller
0339
Main contactor engaging
failure of RL motor
controller
0439
Main contactor engaging
failure of RR motor
controller
0041
High voltage at slider end
of accelerator of pump
motor controller
1. Accelerator wiring
interupted;
2. Excessively high
output voltage at slider
end of accelerator.
Measure the output voltage at the slider end
of accelerator to check if it is too high, replace
the accelerator if necessary.
Note：The pins #16 of the 35–pin controller
connector is for accelerator slider end input.
0141
High voltage at slider end
of accelerator of FL motor
controller
0241
High voltage at slider end
of accelerator of FR motor
controller
