© Oct 2020 6-30 AB18EJ&18HJ Maintenance Manual
REPAIR PROCEDURES
Fault
code
Description
Cause Check
3. Check the motor and controller.
0273
Motor rotary choke of FR
motor controller
0373
Motor rotary choke of RL
motor controller
0473
Motor rotary choke of RR
motor controller
0077
System distress of pump
motor controller
1. The processor
discovers illegal and
reduntant data;
2. The processor inside
the controller fails;
3. The processor
discovers the switching
signal exceeds the
threshold by 100ms (if
the fault occurs
repeatedly, please
check if the switch gets
wet or damaged).
1. Check the internal micro-processor for
damage;
2. Check input signals of all switches, and
ensure the switches free of wetting or
damage.
0177
System distress of FL
motor controller
0277
System distress of FR
motor controller
0377
System distress of RL
motor controller
0477
System distress of RR
motor controller
0087
Motor matching failure of
pump motor controller
Description of motor matching
failure codes:
0=Normal;
1=Encoder signal received,
pseudo not identified, manul
setup of the encoder pulse
required;
2=Motor temp sensor failure;
3=Motor high-temp response
failure;
4=Motor overheat response
failure;
5=Motor low-temmp response
failure;
6=Low-volts response failure;
7=High-volts response failure;
8=Controller fails to detect the
encoder signal;
9=Motor setup exceeding the
range
Check the encoder and motor and ensure
correct wiring
0187
Motor matching failure of
FL motor controller
0287
Motor matching failure of
FR motor controller
0387
Motor matching failure of
RL motor controller
0487
Motor matching failure of
RR motor controller
0089
Motor type error of pump
motor controller
Motor type data setup out
of range
Modify the motor type data
0189
Motor type error of FL
motor controller
0289
Motor type error of FR
motor controller
0389
Motor type error of RL
motor controller
0489
Motor type error of RR
motor controller
0091
VCL/OS mismatch of pump
motor controller
Controller program error Update the program to the correct version.
0191
VCL/OS mismatch of FL
motor controller
