GTJZ0608E&0808E Operation Manual 1-1 © Mar 2021
1 MACHINE SPECIFICATIONS
Table 1-1 GTJZ0608E Specifications
MEASURE
0608E (METRIC) 2132E (IMPERIAL)
DIMENSION
Max. platform height
6.3m 20 ft 8 in.
Max. working height
8.3m 27 ft 3 in.
Max. horizontal extension 0.9m 3 ft
Length
2.46m 8 ft
Width 0.83m 2 ft 8.7 in.
Height (stowed, rails folded)
1.84m 6 ft
Height (stowed, rails up)
2.24m 7 ft 4 in.
Wheel base 1.88m 6 ft 2 in.
Wheel span
0.7m 2 ft 4 in.
Ground clearance (pothole guards
retracted)
100mm
4 in.
Ground clearance (pothole guards
deployed)
25mm 0.98 in.
Tire size (diameter × width / type) φ380x125mm/Solid φ15x5 in./Solid
Platform dimension (Length × Width ×
height)
2.30mx0.8mx1.1m 7 ft 6.5 in. x2 ft 7.5 in. x3 ft 7 in.
PERFORMANCE
Rated load capacity of platform 380Kg
838 lb
Max. load capability of extended platform 120kg
265 lb
Max. platform occupancy (indoor/outdoor) 2 person(indoor)/1 person(outdoor)
Drive speed (stowed)
0～4km/h
0～2.5mph
Drive speed (raised)
0～0.8km/h
0～0.5mph
Uptime (in a no-load state)
25～30 s
Downtime (in a no-load state)
30～35 s
Gradeability
25%
Max. allowable inclination
3°(Front to back)/1.5°(Left to right)
Turning radius (inside)
0 0
Turning radius (outside)
2.1m 6 ft 10.7 in.
Rated load capacity of a single tire 1180kg
2601 lb
