© Mar 2021 7-4 GTJZ0608E&0808E Operation Manual
OPERATING THE MACHINE
TIPPING HAZARD
When the machine tilts, please drive
at low speed.
When the tilt alarm sounds, any oper-
ation of the machine is forbidden ex-
cept lowering, and only when the
factors that cause the tilting are elimi-
nated can the machine continue
operating.
1. When the machine is in stowed position, two speed
modes (high/low speed) are available for selection.
2. Move the drive high/low speed select switch to se-
lect the desired speed. The low drive speed indica-
tor light on indicates the low speed mode is active,
the low drive speed indicator light off indicates the
high speed mode is active.
When the machine is in operating position, only the low
speed is available for selection. The high speed mode
cannot be selected by moving the drive high/low speed
select switch.
OPERATING WITH THE
PLATFORM CONTROLLER
ON THE GROUND
Before operating the machine with the platform control-
ler on the ground:
1. Keep a safe distance between the operator, ma-
chine and fixed platform.
2. Pay attention to the traveling direction of the ma-
chine when using the controller.
EXTENDING/RETRACTING
THE PLATFORM
UNSAFE OPERATION HAZARD
• While the platform is extending,
do not stand on the platform
extension. The platform extension
can be secured on three slots, do
not operate on the platform
extension that has not been
secured.
1. Press down the pedal, grasp the rail of extension
platform and push to extend the platform.
2. Press down the pedal, grasp the rail of extension
platform and pull to retract the platform.
3. Release the pedal, insert the extension platform
end into the slot to secure the extension platform.
FOLDING/UNFOLDING
PLATFORM RAILS
UNSAFE OPERATION HAZARD
• Do not fold the rails while the
machine is working.
• Fold/unfold the rails only when
the machine is stowed and
extension platform fully retracted.
CRUSH HAZARD
• Do not allow hands or arms to get
close to any place that may have
crush hazards.
The platform rails can be foldable for convenient
transportation. Unfold the rails when using the
machine. The machine includes a foldable railing for
the platform extension and a foldable railing for the
fixed platform. Fasten all parts of the railings at the
appropriate positions using the four wire rope safety
pins.
To fold the rails：
1. Remove the platform control box and support.
2. Remove the both wire rope safety pins at the front
end of the extension platform. Fold the front end rail
of extension platform. Do not reach your hands into
the place that may have pinch hazards.
3. Fold down the rails on both sides. Do not reach
your hands into the place that may have pinch
hazards.
4. Remove the both wire rope safety pins at the rear
end of the fixed platform.
5. Carefully open the door and stand on the ladder or
ground.
To Next Page
