OPERATING THE MACHINE
GTTZ10EJ Operation Manual 7-5 © Mar. 2022
1. Open the right turntable cover, and locate the
handle of hand pump.
2. Insert the handle into the hole of hand pump as
indicated.
3. While pressing the button at the end of turntable
rotate valve, push and pull the handle up and down,
the turntable should rotate clockwise.
4. Pull out the ring at the end of the turntable rotate
valve, and push and pull the handle up and down,
the turntable should rotate counterclockwise.
To steer
Figure 7-6
1. Open the right turntable cover, and locate the
handle of hand pump.
2. Insert the handle into the hole of hand pump as
indicated.
3. While pressing the ring of the button at the end of
steer valve, push and pull the handle up and down,
the machine should steer right.
4. Pull out the ring of steer valve, and push and pull
the handle up and down, the machine should steer
left.
EMERGENCY TOWING/
DRAGGING
UNSAFE OPERATION HAZARD
• Unless in case of emergency
situations, machine
malfunction, power loss or
loading/unloading, it is strictly
prohibited to tow or drag the
machine.
• When towing/dragging the
machine, there should be no
person in the platform.
• Before towing/dragging the
machine, ensure that the
machine is in stowed position
with the turntable securely
locked and platform free of any
tools or objects.
• Do not tow/drag the machine
with the engine started or the
drive hub engaged.
• The machine must on a level
surface or secured before
releasing the brake.
• The towing/dragging of the
machine must follow the local
laws and traffic rules.
NOTICE
The allowable towing speed is 3km/h (1.9mph), the
maximum towing distance is 500m (0.3mile).
Method 1：
1. Choke wheels securely to prevent motion of the
machine.
2. Be sure the path is clear of obstructions, and the
power disconnect switch in off position.
3. Move upward the the brake release switch.
To Next Page
