SIP 01332 - Page 17

16
N O D E S C R I P T I O N Q T Y
A-01
Base 1
A-02 Left side panel for base 1
A-03
Right side panel for base 1
A-04
Flat washer 6 20
A-05
Cross recessed pan head screws M6 X 10 12
A-06
Graduated plate 1
A-07 Cable-grand 1
A-08
Rubber washer of switch box 1
A-09 Switch box 1
A-10
Switch 1
A-11 Flat washer 6 8
A-12
Cross recessed pan head screws M4 X 10 6
A-13
Dust collect tube joint 1
A-14
Hexagon nut M 6 4
A-15
Hexagon head bolt M8 X 12 2 8
A-16 Flat washer 8 5 6
A-17
Hexagon nut M 8 2 8
A-18 Stand level foot 4
A-19
Front panel for stand 1
A-20 Rear panel for stand 1
A-21
Left side panel for stand 1
A-22
Right side panel for stand 1
A-23
Cross recessed pan head screws M 6 X 16 4
A-24
Cross recessed pan head tapping screws ST 4.0 X 12 2
A-25 Switch bottom plate 1
A-26
Bottom plate rubber washer 1
N/A
M
ounting Bracket for Wheel Kit (WD03-00521)
1
