Contents
1. Contents P1
2. Please read first P1
3. Specification P2
4. Safety P2
4.1 Specified conditions of use P2
4.2 General safety instructions P2
4.3 Symbols used throughout these instructions P4
4.4 Safety devices P4
5. Unpacking P4
6. Special product features P4
7. Operation elements P4
8. Initial operation P5
8.1 Replacing the fuse in the switch box P5
8.2 Installing the extension table P6
8.3 Installing the front rail P6
8.4 Installing the rear rail P7
8.5 Installing the rip fence P7
8.6 Installing the blade guard P8
8.7 Connection of dust collector P8
8.8 Mains connection P8
9. Operation P8
9.1 Sawing P9
9.2 Mitre cuts P9
9.3 Rip cuts with rip fence P9
10. care and maintenance P10
10.1 Saw blade change P10
10.2 Cleaning the saw P11
10.3 Machine storage P11
10.4 Maintenance P11
11. Tips and tricks P11
12. Repairs P11
13. Trouble shooting P12
14. transportation P14
15. Circuit diagrams P14
16. Instruction for thermo cutout in motor P14
17. Diagrams and parts lists P15
2. Please Read First
WARNING!
When using electric tools basic safety
precautions should always be followed to reduce the risk
of fire, electric shock and personal injury including the
following.
● Read these instructions before attempting to operate
this product and save these Instructions.
● If you notice transport damage while unpacking, notify
your supplier immediately. Do not operate the saw!
● Dispose of the packing in an environmentally friendly
manner. Take to a proper collecting point.
● Keep these instructions for reference on any issues you
may be uncertain about.
ATTENTION:
FOR YOUR OWN SAFETY: READ AND UNDERSTAND
THE OWNER'S MANUAL BEFORE OPERATING
MACHINE.
1. Set up the saw on a firm, level, non-slip, vibration-free
base. Keep the site free of tripping hazards. Ensure
adequate lighting conditions.
2. Do not wear loose fitting clothes, remove rings,
wristwatch and bracelets. Tie back long hair.
3. Wear safety goggles and face shield if operation is
dusty. Wear ear defenders.
4. Do not use the saw in a moist or wet environment, or in
the vicinity of combustible liquids and gases.
5. The saw must only be operated with all correctly
mounted guards.
6. Never use cracked or distorted saw blades. Only user
sharp saw blades.
7. Use a pushing stick when rip sawing narrow
work-piece.
Limitations on ambient conditions
The circular saw bench is designed for operating on the
site:
The height above sea level doesn't exceed 1000m;
The temperature range of air doesn't exceed 0°C～
40°C.
