N O D E S C R I P T I O N Q T Y

B-0 1 Rear rail 1

B-0 2 Square head bolt M8 X 25 1 0

B-0 3 Cross recessed countersunk head screws M5 X 6 5

B-0 4 Cover plate 1

B-0 5 Work table 1

B-0 6 Extension table 2

B-0 7 Flat washer 8 1 8

B-0 8 Hexagon nut M 8 1 0

B-0 9 Hexagon head bolt M8 X 20 8

B-1 0 Slotted set screw with flat point M10 X 80 4

B-1 1 Hexagon nut M10 1 2

B-1 2 Cross recessed pan head tapping screw ST4.0 X 12 6

B-1 3 Flat washer 4 6

B-1 4 Left end cap for front rail 1

B-1 5 Front rail 1

B-1 6 Right end cap for front rail 1

B-1 7 Square nut M5 1 2

B-1 8 Rack 4

B-1 9 Lock washers external teeth 1 2

B-2 0 Cross recessed pan head screw M5 X 8 1 2

B-2 1 Flat washer 6 2

B-2 2 Hexagon socket cap screw M 6 X 15 2

B-2 3 Neck chain 2

B-2 4 Dust collect tube 1

B-2 5 Dust collect frame 1

SIP 01332 User Manual
