NO DESCRIPTION QTY NO DESCRIPTION QTY
D-01 Blade nut M16(left hand) 1 D-39 HANDLE 2
D-02 Outer blade washer 1 D-40 Handle bolt 2
D-03 Blade 1
D-04 A-belt 1
D-41 Cross recessed pan head screw
M6x16
4
D-05 Pulley 1 D-42 Flat washer 6 8
D-06 Key A-type 1 D-43 Ball bracket 2
D-07 Arbor shaft 1 D-44 Thread rod ball 1
D-08 Bearing 80203 2 D-45 Spring dowel 4x28 1
D-09 Arbor shaft sleeve 1 D-46 Adjusting thread rod 1
D-10 Arbor shaft bush 1 D-47 Worm-wheel connecting rod nail A 1
D-11 Circlips for hole D=40 2 D-48 Worm-wheel connecting rod 1
D-12 Arbor shaft end bush 1 D-49 Worm-wheel connecting rod nail B 1
D-13 Press washer 1 D-50 Connecting rod bush 1
D-14 Single coil spring lock washer 6 1 D-51 Hexagon nut M6 4
D-15 Hexagon head bolt M6x16 1 D-52 Adjusting frame 1
D-16 Hexagon head bolt M8x20 2 D-53 Circlips for shaft D=24 2
D-17 Flat washer 8 18 D-54 Knuckle 1
D-18 Press board for riving knife 1
D-19 Riving knife 1
D-55
Hexagon socket cap head screw
M6x12
1
D-20 Flower nut 1 D-56 Height adjustment rod 1
D-21 Large washer 6 2 D-57 Circlips for shaft D=18 1
D-22 Step bolt M6x46 1 D-58 Motor 1
D-23 Blade guard 1 D-59 Hexagon head bolt M8x40 7
D-24 Hexagon nut M8 13 D-60 Key 8x7x50 1
D-25 Hexagon socket set screw with flat
point M8x25
4 D-61
Hexagon socket set screw with flat
point M6x9
1
D-26 Hexagon socket cap head screw
M10x30
1 D-62 Hexagon socket set screw with flat
point M6x6
1
D-27 Locking nut with plastic insert M8 2 D-63 Motor wheel 1
D-28 Riving Knife bracket 1
D-29 Connecting rod 1
D-64
Hexagon socket cap head screw
M8x24
7
D-65 Single coil spring lock washer 8 7 D-30 Cross recessed countersunk head
screw M8x20
1
D-66 Rotation press block 2
D-31 Connecting rod bush 1 D-67 Adjusting cradle 1
D-68 Hexagon head bolt M8x75 1 D-32 Cross recessed countersunk head
screw M8x30
1
D-69 Hexagon nut M12 1
D-33 Hexagon head bolt M8x65 1 D-70 Single coil spring lock washer 12 1
D-34 Locking nut for motor base 2 D-71 Worm-wheel 1
D-35 Motor base 1 D-72 Eccentric sleeve 1
D-36 Hexagon socket cap head screw
M5x12
2 D-73 Hexagon socket cap head screw
M8x30
1
D-37 Large washer 5 4 D-74 Worm-wheel shaft nail 1
D-38 Hand wheel 2 D-75 Locking block 1
