25
N O D E S C R I P T I O N Q T Y
E-01 Round head rivets with small head Φ3 x 7 2
E-02 Hexagon nut M8 1
E-03 Flat washer 8 1
E-04 Round head rivets with small head Φ3 x 13 2
E-05 Lock plate 1
E-06 Lock spring 1
E-07 Lock block 1
E-08 Spring ring D6 2
E-09 Rolling wheel 1
E-10 Rip fence 1
E-11 Cross recessed countersunk head screw M6x12 4
E-12 Fence plate 1
E-13 Square nut M6 4
E-14 Cross recessed pan head screw M6x16 4
E-15 Board instead of nut 1
E-16 Cross recessed countersunk head tapping screw ST4.0x12 6
E-17 Left end cap for scale indicator housing 1
E-18 Scale indicator housing 1
E-19 Right end cap for scale indicator housing 1
E-20 Scale indicator 1
E-21 Lock washer external teeth 5 3
E-22 Cross recessed pan head screw M5x10 3
E-23 Square nut 3
E-24 Small gear 1
E-25 Gear rod 1
E-26 Eccentric wheel 1
E-27 Gear rod frame 1
E-28 Spring for gear rod 1
E-29 Hexagon socket set screw with flat point M6x5 2
E-30 Rip fence handle 1
E-31 Rear board 1
E-32 Pin Φ5x16 2
E-33 Rear block 1
E-34 Lock eccentric rod 1
E-35 Lock eccentric 2
E-36 Rip fence lock rod 1
E-37 Rip fence handle 1
E-38 Rip fence cover 1
