Introduction
3
2. Physical Description
Front Panel
On the Access Point’s front panel there are LED lights that inform you of the Access Point’s
current status. Below is an explanation of each LED.
LED Color Status Description
Lit Power is supplied.
Power Green
Off No Power.
Flash Antenna is transmitting or receiving data.
WLAN Green
Off
Antenna is not transmitting or receiving data.
On A valid link is established.
Flash It is transmitting or receiving data. LAN Green
Off No link is established.
