MK15E User Manual V1.1
17
2022 SIYI Technology, All Rights Reserved
Interface & Ports
Charging: Type-C
Firmware Upgrade: DATA (4-Pin)
Mobile Network: SIM Card Slot
External Storage: TF Card Slot
Tripod Connect: 1/4-inch Screw Hole
Video Output: Standard HDMI
External RTK: DATA (4-Pin)
Data Transfer: USB-A
Waterproof Level
IP53
Working Temperature
-10℃ ~ 55℃
Air Unit (Air Unit)
Signal Output
16 channels of SBUS
5 channels of PWM
Interface & Ports
S.BUS: 3-Pin
Datalink (to FC): UART 4-Pin
PWM Channel 1-5: 6-Pin
2 x Video Input: 8-Pin
Firmware Upgrade: Type-C
Dimension
(Antenna Detached)
75 x 48 x 17 mm (The height excludes the fan; the height
of the fan is 6 mm)
Weight
(Antenna Detached)
116 g
Antenna Gain
5 dBi
Power Input
25.2 ~ 58.8 V
(6S ~ 14S)
Working Temperature
-10℃ ~ 55℃
Camera & Searchlight
Camera Angle
FOV 120°
Dimension
106 x 25 x 41 mm
Weight
108 g
Searchlight Power
Consumption
8 W
