Mark
Diagram ① or ② means that MK15E Air Unit connects to only one IP camera or pod.
You can use SIYI IP67 Camera (with searchlights), SIYI IP Camera, or Third-party IP
Cameras / Pods. This diagram works when you purchase MK15E AG FPV Combo, or you
purchase other MK15E combo to work with your available IP cameras / pod.
Diagram ① and ② means that MK15E Air Unit connects to two IP cameras or pods. You
can use SIYI IP67 Camera (with searchlights), SIYI IP Camera, or Third-party IP Cameras
/ Pods. This diagram works when you purchase MK15E AG Dual FPV Combo, or you
purchase a spare IP camera / pod to work with your available MK15E combo. The two video
streams will display in the same screen in SIYI FPV app, or some specific ground station
software. The display can be switched.
Diagram ③ means that MK15E Air Unit connects to an HDMI camera or pod through an
HDMI converter. This diagram works when you purchase MK15E Enterprise HDMI Combo
to work with your available HDMI camera / pod, or you purchase the HDMI converter alone
to work with your available MK15E combo and HDMI IP cameras / pod.
Diagram ④ means MK15E transmitter outputs video stream to an external monitor
through its standard HDMI port. The video stream will be the same with MK15E screen
display.
