PRODUCT SPECIFICATIONS
Enclosure and cabinet mechanical drawings
SKF Multilog On-line System IMx-16Plus
User Manual
Revision Letter A
57 (66)
Important safety warning for IP rated cabinets:
Figure 20 CMON 4150 cabinet with pre-drilled gland area
Always utilise all provided fixing points to secure the cabinet to the
mounting surface.
