PRODUCT SPECIFICATIONS
Mobile data / Wi-Fi antenna (optional)
SKF Multilog On-line System IMx-16Plus
User Manual
Revision Letter A
Figure 21 below, illustrates the IP65 cabinet, without pre-drilling.
Figure 21 CMON 4151 cabinet without pre-drilled gland area
3.5 Mobile data / Wi-Fi antenna (optional)
An optional antenna is available under SKF part number CMON 4142. This is the
same type of mobile data / Wi-Fi antenna used in the SKF Multilog IMx-Rail and the
images shown in the figure below, show its usage there.
b) Internal (mounting) view
Figure 22 Mobile data / Wi-Fi antenna (optional)
