Continuation of "Technical Data" table
Data universally applicable to KFG, KFGS; KFGC
Description Field of application Key data/indicator
Conditions for electrical connections
Rated voltage
Power consumption (load-dependent)
Power consumption (maximum)
Pump starting current (approx. 20 ms)
Max. pre-connected fuse
12 VDC
12 VDC
2.4 A
1
)
< 5 A
9 A
10 A
2
)
3
)
24 VDC
24 VDC
1.25 A
1
)
< 2.5 A
4.5 A
7.5 A
2
)
3
)
Fill level switch W1 NLGI 2 Fault notification via pulse
Fill level switch W1_smooth NLGI 2 Fault notification via energized contact
Fill level switch W2 
Electrically controlled
pressure relief valve
12/24 VDC or 230 VAC
1) Typical value at ambient temperature = 25 °C and operating pressure = 150 bar
2) Fuse per DIN 72581 T.3
3) Conductor: cross-section 1.5 mm2, length ≤ 12 m
16. Technical data
KFGS
KFG
KFGC
