SKF ST-1240-GRAPH - 3. TECHNICAL SPECIFICATIONS

18
3. TECHNICAL SPECIFICATIONS
Operation temperature


Operating voltage
115 V / 230 VAC, automatic range selection
Operating voltage range
93 to 132 V AC; 186 to 264 V AC
Operating voltage frequency
47 to 63 Hz
Power consumption
5.4 A/115 V AC, 2.2 A/230 V AC
Fuse
Circuit breaker, 6 A
Cable connections
Screw terminals for 2.5 mm² wires
Casing
380 x 300 x 210mm (w x h x d), painted RAL 7035
Protection class
IP65
Weight
10 kg
User interface

Ethernet and USB port
EMC standards
EN61000-6-4, EN61000-6-2
IEC 61000 - 4 - 3, 10 V/m, control panel HMI
FCC Class A, control panel HMI
Electrical safety standards
EN61010-1
Power supply according to EN60950
IEC 61131-2, control panel HMI
UL 1604, control panel HMI
UL 508, control panel HMI
