SKF ST-1240-GRAPH - Page 21

21
22
Pressure transmitter/switch channel 2
line 2 -

32
Pressure transmitter/switch channel 2
line 2 +
23
Low limit channel 2 (Master / LL1) (+)
contact input
33
0 V (Master / LL1) (-)
24
Channel 2 line 1 control or channel 1
shut-off valve control
24V/ 2A
34
0 V
25
Channel 2 line 2 control or channel 2
shut-off valve control
24V/ 2A
35
0 V
26
Channel 2 pump control (Master / PC2)
24V/2A
36
0 V
27
Channel 2 ePump operating voltage
24V/5A
37
0 V
28
Channel 2 Doser monitor operating
voltage
or Channel 2 pump control voltage
(Slave / PC2)
24V/2A
38
0 V
29
Channel 2 Doser monitor contact (+)
or Low limit channel 2 (Slave / LL2) (+)
or Spray air pressure switch AS2 (+)
***)
contact input
39
Channel 2 Doser monitor contact (-)
or Low limit channel 2 (Slave / LL2) (-)
or Spray air pressure switch AS2 (-)
***)
contact input
30
Channel 2 spray air control AC2 (+)
24V/2A
40
0 V
Connector XC
41
24 V
42
24 V
43
0 V
44
0 V
Connector XD
51
RS422 R+
Online 1440 connection
54
RS422 R-
52
RS422 T+
55
RS422 T-
53
Warning output +
-24V/2A , CB105ver1,
- Relay contact 50V/2A max. on CB105ver2
56
Warning output -
0V, on CB105ver1,
- relay contact 50V/2A max. on CB105ver2
Connector XE
