Parameter
Description
Lubrication channel
operation mode
(in the picture
SG2, DuoFlex)
Operation mode codes:
" SG1, MonoFlex: single-line grease lubrication system
" SG2, DuoFlex: dual-line grease lubrication system
" SG1E, MonoFlex: single-line grease lubrication system, pressurization
maintaining operation
" SG2E, DuoFlex: dual-line grease lubrication system, pressurization
maintaining operation
" ML1, MonoFlex: single-line Multilube lubrication system
" ML2, DuoFlex: : dual-line Multilube lubrication system
" SG1S, MonoFlex: single-line grease spray lubrication system
" SG2S, DuoFlex: dual-line grease spray lubrication system
" P1, ProFlex: lubrication system with progressive feeders
" OS, MonoFlex: oil lubrication system
Lubrication channel
name
(in the picture Conveyor1)
Channel named with a description of the machine to be lubricated
The maximum length of the name is 10 characters.
Channel pressure
monitoring unit
(in the picture Pressure
transmitters)
Options:
" Pressure transmitters: Pressure transmitters have been installed to the
lubrication lines. Pressure can be presented in numeric values.
" Pressure switches: Pressure switches have been installed to the
lubrication lines.
Pressure can be presented as modes ON/OFF.
In the ProFlex system,this field cannot be set.
Lub.cycle
Method of calculating the lubrication cycle
" TIME: lubrication cycle is based on time
" PULS: lubrication cycle is based on the pulses received from the device
being lubricated
Air monitoring
" YES: Air feed to the spray nozzle is monitored with a pressure switch in a
grease spraying system.
" NO: Air monitoring is not in use.
Customer spef.
Customer-specific parameters
" 0, no customer-specific functions
" 1, extra lubrication when interlocking mode is switched off
Doser monitor
" YES/Alarm: Doser operation indicators are in use in the DuoFlex

" YES/Warning: Doser operation indicators are in use in the Duoflex

" NO: Doser operation indicators are not in use in the lubrication channel.
Function buttons
" Out
" Passwd.: Entering password.
" Common conf: Additional page for general settings which are not channel-specific.
