128
NOTE: Use precision digital tachometer for engine RPM adjustment.
NOTE: The adjustment has an effect on high RPM only.
To adjust, turn calibration screws.
Calibration screw has a notch on top of its head.
1. Notch
Governor cup has 6 positions numbered 2 to 6. Note that in position 1
the number is substitued by a dot (due to its location on casting).
1. Position 1 (not numbered)
A16D0FA
1
A16D0GA
1
