ON-VEHICLE IMPORTANT INSTRUCTIONS

Please read the following instructions carefully before operating snow-

mobile. Have all damaged decals replaced by an authorized SKI-DOO

dealer.

LOCATION OF IMPORTANT INSTRUCTIONS

A32A02E

13452

Mmo2003-003a.book Page 20 Tuesday, March 19, 2002 2:22 PM
