32
MECHANICAL BRAKE
To engage mechanism, squeeze brake lever and maintain while pull-
ing button with the other hand. There are 2 retaining notches on but-
ton lever; pull button until it locks on a notch then release brake lever.
To release mechanism, squeeze brake lever then fully push parking
brake button. Always release parking brake before riding.
TYPICAL
Step : Squeeze and hold
Step : Fully pull
A25H30A
1
2
1
2
Mmo2003-003a.book Page 32 Tuesday, March 19, 2002 2:22 PM
