TYPICAL — BACKREST SUPPORT ANGLE

1. Loosen top knob to adjust then retighten

TYPICAL — BACKREST HEIGHT

1. Loosen center knobs (both sides) to adjust then retighten

A03A0KC

A03A0KB
