Page 24 of 56
SKIPPER Electronics AS
Edition: 2021-09-16
ESN100 Operation and Installation Manual
Chapter: System Setup
User Dened Alert Values
Alert Range Default
Shallow water (Keel) 1-99 m 10m
Deep Water (Keel) 2-5000m
Can not be less than shallow water
alarm
OFF
Settings
Setting Selection Default Description
Alert group DEFAULT, CAM1,
CAM2, BAM1, BAM2
Default The LWE group for alert messages
to be sent on
Default is the group set for the
system in Screen setup - Networks
BAM/CAM SFI XXYYYY
(X is letter Y is number)
CA1235 The Identity of the centralised
alarm system (normally CA or IN)
Alert type ALF, ALR ALF The type of alert messages to be
sent, ALF or ALR with or without
acknowledge of shallow water
Escalation time 1m, 2,3,4,5 m 2 min Warnings will be escalated after
this time.
