– Press extractor -T10530- into the bore of the ignition coil -1-
as far as the stop.
– Tighten nuts -2- in -direction of arrow-.
– Remove ignition coil with extractor -T10530- in
-direction of arrow- out of the camshaft housing.
Install
Installation is carried out in the reverse order. When installing,
observe the following:
– Insert all ignition coils loosely into the spark plug shaft.
– Align ignition coils to the connectors and simultaneously at‐
tach all connections to the ignition coils.
– Press ignition coils onto the spark plugs evenly by hand (do
not use an impact tool).
Tightening torque
Component Nm
Screw for ignition coil 8 Nm
1.3 Removing and installing knock sensor 1
- G61-
Removing
– Remove AC compressor from holder and strap up ⇒ Heating,
Air Conditioning; Rep. gr. 87 .
– Separate electrical plug connection -1-.
– Release screw -2- and remove knock sensor 1 - G61- .
Install
Installation is carried out in the reverse order. When installing,
observe the following:
– Install AC compressor ⇒ Heating, Air Conditioning; Rep. gr.
87 .
Tightening torque
Component Nm
Screw for knock sensor 20 Nm
Octavia III 2013 ➤ , Octavia III 2014 ➤
1.2/63; 77 kW TSI engine - Edition 11.2014
1. Ignition system 283
